Modeling, Control, and Performance Evaluation of Grid-Tied Hybrid PV/Wind Power Generation System: Case Study of Gabel El-Zeit Region, Egypt

 ABSTRACT:



The potential for utilizing clean energy technologies in Egypt is excellent given the abundant solar irradiation and wind resources. This paper provides detailed design, control strategy, and performance evaluation of a grid-connected large-scale PV/wind hybrid power system in Gabel El-Zeit region located along the coast of the Red Sea, Egypt. The proposed hybrid power system consists of 50 MW PV station and 200 MW wind farm and interconnected with the electrical grid through the main Point of Common Coupling (PCC) busbar to enhance the system performance. The hybrid power system is controlled to operate at the unity power factor and also the Maximum Power Point Tracking (MPPT) technique is applied to extract the maximum power during the climatic conditions changes. Modeling and simulation of the hybrid power system have been performed using MATLAB/SIMULINK environment. Moreover, the paper presented a comprehensive case study about the realistic monthly variations of solar irradiance and wind speed in the study region to validate the effectiveness of the proposed MPPT techniques and the used control strategy. The simulation results illustrate that the total annual electricity generation from the hybrid power system is 1509.85 GWh/year, where 118.15 GWh/year (7.83 %) generates from the PV station and 1391.7 GWh/year (92.17%) comes from the wind farm. Furthermore, the hybrid power system successfully operates at the unity power factor since the injected reactive power is kept at zero.

KEYWORDS:

1.      PV

2.      wind

3.      hybrid system

4.      Gamesa G80

5.      Gabel El-Zeit

6.      Egypt

SOFTWARE: MATLAB/SIMULINK

BLOCK DIAGRAM:



FIGURE 1. Configuration of the proposed PV/wind hybrid system.

 EXPECTED SIMULATION RESULTS:



FIGURE 2. PV array side results.

FIGURE 3. Dynamic action of the VSI controller.

FIGURE 4. Dynamic performance of the PV station at the B1-bus.

FIGURE 5. Gamesa wind turbine results

FIGURE 6. Dynamic performance of the wind speed at the B2-bus.

FIGURE 7. Performance of the hybrid system at the PCC bus.

 CONCLUSION:

This paper presented the detailed design, control strategy, and performance analysis of 250 MW grid-connected PV/wind hybrid power system in Gabel El-Zeit region, Egypt. This area is characterized by a good level of solar irradiation with an annual average value of 199.75 kWh/m2 and powerful wind speed with an average value of 14.08 m/s at 60 m hub height. The proposed hybrid power system consists of 50MW PV station based Sanyo HIP-200B PV module and 200 MW wind farm based Gamesa G80 wind turbine and it is inte- grated with the grid through the main PCC bus to support the system performance. The hybrid power system is adjusted to work at the unity power factor and also the MPPT algorithms are applied to capture the optimum power from the hybrid system under the changes of climatic conditions. Adaptive InCond MPPT technique based variable step-size is applied to the boost converter to extract the maximum power from the PV station during the solar irradiance variation. On the other hand, a modi_ed P&O MPPT strategy is implemented on the RSC of DFIG to obtain the maximum power from the wind farm during the change of wind speed.

Moreover, this paper analyzed the actual monthly changes of solar irradiance and wind speed in the study area to evaluate the dynamic performance of the hybrid system and validate the ef_ciency of the proposed MPPT techniques and the control systems. The simulation results have illustrated that the proposed InCond MPPT algorithm tracks accurately the MPPs, where the PV station power increases signi_cantly from 8.9MWin January to its maximum value (17.9 MW) in June, then it falls drastically to the minimum value of 8.2MW in December. Also, the DC-link voltage controller of the VSI adjusts successfully the DC-link voltage at its reference value (500 V) regardless of the solar irradiance variation.

Furthermore, the proposed P&O MPPT strategy sustains the optimal value of the wind turbine performance coef_cient, Cp D 0:48, to extract the maximum power from the wind farm during the change of wind speed. Therefore, the active power rises dramatically from 127.6 MW in January to the rated value (200 MW) in June, then it decreases gradually until reaching the minimum value of 112.4MWin November. Besides, the GSC controller has successfully stabilized the DC-bus voltage to the desired value (1150 V) regardless of the wind speed change.

Additionally, the simulation results have shown that the total annual electricity generation from the hybrid power system is 1509.85 GWh/year, where 118.15 GWh/year (7.83 %) generates from the PV station and 1391.7 GWh/year (92.17%) comes from the wind farm. Moreover, the control system always maintains the hybrid power system at the unity power factor as the injected reactive power is kept at zero. Also, the PCC bus voltage is sustained perfectly constant irrespective of the changes in climatic conditions and the magnitude of generated active power.

REFERENCES:

[1] K. D. Patlitzianas, ``Solar energy in Egypt: Signi_cant business opportunities,'' Renew. Energy, vol. 36, no. 9, pp. 2305_2311, Sep. 2011.

[2] H. M. Sultan, O. N. Kuznetsov, and A. A. Z. Diab, ``Site selection of large-scale grid-connected solar PV system in egypt,'' in Proc. IEEE Conf. Russian Young Researchers Electr. Electron. Eng. (EIConRus), Jan. 2018, pp. 813_818.

[3] Ministry of Electricity and Renewable Energy. (2018). New and Renewable Energy Authority (NREA) Annual Report for the Egypt. [Online]. Available: http://www.nrea.gov.eg/Content/reports/Englishv 2AnnualReport.pdf

[4] M. EL-Shimy, ``Viability analysis of PV power plants in Egypt,'' Renew. Energy, vol. 34, no. 10, pp. 2187_2196, Oct. 2009.

[5] M. G. M. A. Y. Hatata and M. Rana Elmahdy, ``Analysis of wind data and assessing wind energy potentiality for selected locations in Egypt,'' Int. J. Sci. Eng. Res., vol. 6, p. 6, Mar. 2015.
