Full Soft-Switching High Step-Up Current-Fed DC-DC Converters with Reduced Conduction Losses

 ABSTRACT:

Two variants of the full soft-switching high step-up DC-DC converter are proposed. The main advantage of the converters is the minimized conduction losses by the use of the four-quadrant switches and a specific control algorithm. Simulation was performed to verify the principle of operation and to estimate the losses.

KEYWORDS:

1.      DC-DC power converters

2.       Photovoltaic systems

3.      Soft switching

4.       Step-up

5.       Isolated

SOFTWARE: MATLAB/SIMULINK

 CIRCUIT DIAGRAM:

Fig. 1. Full soft-switching high step-up DC-DC converter

Fig. 2. Proposed converter topology with four four-quadrant switches.

EXPECTED SIMULATION RESULTS:

Fig. 3. Simulated voltage and current waveforms of S1 (a), S2 (b), S7.1 (c), S5 (d) for the proposed converter topology with a single four-quadrant switch

CONCLUSION:

The proposed converters allow soft-switching of the both inverter and rectifier switches without any auxiliary passive elements and clamping circuits.

As seen from simulation results, the topology with a single four-quadrant switch has higher efficiency than the topology with four four-quadrant switches, but at the same time, it has few disadvantages that could affect the final choice of topology:

- Step-up factor is slightly lower than in the topology with four four-quadrant switches;

- The switching interval e (and the symmetrical interval in another half-period) must be of strictly right duration, which is equal to the time of current redistribution between switches S4 and S2. The shorter duration of this interval will result in high switching losses and, in extreme cases, can lead to damage of the switch S4. The significantly longer duration will result in current increase through the switch S2 and eventually may result in the boost inductor saturation.

- The original topology and the topology with four four quadrant switches does not have the problem with the longer duration of this switching interval and so they have lower requirements to the control system in dynamic mode. This means that proposed converter with four four-quadrant switches allows robust soft-switching commutation, which is hard to achieve in galvanically isolated current-fed DCDC converters.

The main disadvantage of the topologies is the presence of four switches in series in the inverter stage on the path of the current flow during the energy transfer interval. This leads to the conduction losses higher than in the conventional phase shifted full-bridge topology. Nevertheless the switching losses are lower due to the introduced soft-switching. It means that switching frequency could be increased while maintaining the efficiency at acceptable level.

Future work will be devoted to the experimental verification of the proposed converters and further control algorithm optimization.

REFERENCES:

[1] A. Blinov, D. Vinnikov, and V. Ivakhno, “Full soft-switching high stepup dc-dc converter for photovoltaic applications,” 2014 16th European Conference on Power Electronics and Applications (EPE’14-ECCE Europe), pp. 1–7, Aug 2014.

[2] Y. Sokol, Y. Goncharov, V. Ivakhno, V. Zamaruiev, B. Styslo, M. Mezheritskij, A. Blinov, and D. Vinnikov, “Using the separated commutation in two-stage dc/dc converter in order to reduce of the power semiconductor switches’ dynamic losses,” Energy Saving. Power Engineering. Energy Audit, 2014.

[3] A. Blinov, V. Ivakhno, V. Zamaruev, D. Vinnikov, and O. Husev, “Experimental verification of dc/dc converter with full-bridge active rectifier,” 38th Annual Conference on IEEE Industrial Electronics Society (IECON 2012), pp. 5179–5184 , Oct 2012.

[4] R.-Y. Chen, T.-J. Liang, J.-F. Chen, R.-L. Lin, and K.-C. Tseng, “Study and implementation of a current-fed full-bridge boost dc-dc converter with zero-current switching for high-voltage applications,” IEEE Transactions on Industry Applications, vol. 44, no. 4, pp. 1218–1226, July 2008.

[5] J.-F. Chen, R.-Y. Chen, and T.-J. Liang, “Study and implementation of a single-stage current-fed boost pfc converter with zcs for high voltage applications,” IEEE Transactions on Power Electronics, vol. 23, no. 1, pp. 379–386, Jan 2008.

Full Soft-Switching High Step-Up Dc-Dc Converter For Photovoltaic Applications

 ABSTRACT:

In this paper a full soft-switching high step-up DC-DC converter is introduced as an alternative approach to module integrated converters for photovoltaic applications. The presented operation principle and key equations can be used as design guidelines for component and parameter estimation in practical applications. The proposed DC-DC converter was verified by help of simulations and experiments. Power loss analysis based on the semiconductor datasheet values showed that the converter tends to achieve an efficiency of 92. 8% at the maximum power point.

KEYWORDS:

1.      DC-DC power conversion

2.       Photovoltaic power systems

3.       MOSFET switches

SOFTWARE: MATLAB/SIMULINK

CIRCUIT DIAGRAM:

Fig. 1: Generalised topology of the proposed DC-DC converter.

EXPECTED SIMULATION RESULTS:

Fig. 2: Simulated voltage and current waveforms of MOSFET SI (a), MOSFET Tl (b), transformer

primary (c) as well as the input and output voltage and current waveforms (d).

Fig. 3: Converter regulation characteristics at different irradiation levels (a) and cell temperatures (b).

Fig. 4: Experimental voltage and current waveforms of Tl MOSFET (a), SI MOSFET (b) and S2

MOSFET (c).

Fig. 5: Experimental waveforms of the input (a) and output (b) voltage and current.

CONCLUSION:

The proposed high step-up DC-DC converter allows ZVS of the inverter switches and ZCS of the rectifier switches. The operation principle presented and the mathematical analysis of the converter can be used as design guidelines for component and parameter estimation in practical applications. The operation of the converter was verified with the 300 W experimental prototype and the experimental waveforms were found to correspond to the estimated ones. The major limitation of the converter lies in the diodes connected in series to the inverter transistors. The static losses in these diodes will contribute a major portion of the total converter losses. In the future these diodes will be replaced by MOSFETs, external snubber capacitors for rectifier switches will be introduced and the implementation possibilities of wide-bandgap semiconductors will be also addressed.

REFERENCES:

[1] Walker, G.R.; Sernia, P.C., "Cascaded DC-DC converter connection of photo voltaic modules", 33rd Annual Power Electronics Specialists Conference PESC'2002, vol. I, pp.24-29, 2002.

[2] Forcan, M.; Tusevljak, J.; Lubura, S.; Soja, M., "Analyzing and Modeling the Power Optimizer forBoosting Efficiency of PV Panel", IX Symposium Industrial Electronics INDEL'2012, pp. 198-193, Banja Luka, November 01-03,2012.

[3] Kasper, M.; Bortis, D.; Friedli, T.; Kolar, J.W., "Classification and comparative evaluation of PV panel integrated DC-DC converter concepts," Power Electronics and Motion Control Conference (EPEIPEMC), 2012 15th International, pp.LSle.4-1,LSle.4-8, 4-6 Sept. 2012.

[4] Christian Peter Dick "Multi-Resonant Converters as Photovoltaic Module-Integrated Maximum Power Point Tracker", PhD Thesis 2010, available: http://darwin.bth.rwth-aachen.de/opus3/volltexte/20 1 0/3267 /pdf/3267 .pdf

[5] Kasper, Matthias; Ritz, Magdalena; Bortis, Dominik; Kolar, Johann W., "PV Panel-Integrated High Step-up High Efficiency Isolated GaN DC-DC Boost Converter," Proceedings of 2013 35th International Telecommunications Energy Conference 'Smart Power and Efficiency' (INTELEC), pp.I-7, 13 17 Oct. 2013.

Zero-Voltage Switching Galvanically Isolated Current-Fed Full-Bridge DC-DC Converter

ABSTRACT:

This paper presents a new soft-switching technique for the current-fed full-bridge DC-DC converter that enables zero voltage switching of the input side inverter switches. To achieve this, the secondary side voltage doubler rectifier has to be realized with active switches. Two control channels synchronous with the control signals of the inverter switches are added for driving those switches. Zero voltage switching achieved is assisted with the body diodes that conduct current during soft-switching transients as a result of the leakage inductance current shaping from the secondary side. Moreover, the converter does not suffer from voltage overshoots thanks to natural clamping from the secondary side. Theoretical predictions were verified with simulation.

KEYWORDS:

1.      Zero-voltage switching

2.      Current-fed DC-DC converter

3.      Full-bridge

4.      Soft-switching

5.      Switching` control method

SOFTWARE: MATLAB/SIMULINK

 CIRCUIT DIAGRAM:

 Fig. 1. Galvanically isolated full-bridge current-fed DC-DC converter with controlled output rectifier stage.

 EXPECTED SIMULATION RESULTS:

Fig. 2. Simulated current and voltage waveforms along with control signals

of the input and output side switches.

Fig. 3. Experimental current and voltage waveforms.

CONCLUSION:

The novel ZVS technique intended for the galvanically isolated full-bridge current-fed DC-DC converter with the controlled output rectifier stage were presented. It enables full ZVS in the input side current-fed inverter assisted with the leakage inductance and body diodes. Moreover, partial ZCS is provided in the secondary side assisted with the leakage inductance. Simulation study corroborates the theoretical predictions made. Experimental prototype operation was quite similar to the simulation model created in PSIM. Nevertheless, the prototype features oscillations caused by parasitic elements of the circuit and reverse recovery of the body diodes the input side MOSFETs. Further research will be aimed towards derivation of design guidelines that take into account reverse recovery effect and, consequently, result in high efficiency and low parasitic oscillations.

REFERENCES:

[1] Blaabjerg, F.; Zhe Chen; Kjaer, S.B., "Power electronics as efficient interface in dispersed power generation systems," IEEE Transactions on Power Electronics, vol. 19, no. 5, pp. 1184-1194, Sept. 2004.

[2] Kouro, S.; Leon, J.I.; Vinnikov, D.; Franquelo, L.G., "Grid-Connected Photovoltaic Systems: An Overview of Recent Research and Emerging PV Converter Technology," IEEE Industrial Electronics Magazine, vol. 9, no. 1, pp. 47-61, March 2015.

[3] Rathore, A.K.; Prasanna, U., "Comparison of soft-switching voltage-fed and current-fed bi-directional isolated Dc/Dc converters for fuel cell vehicles," in Proc. ISIE’2012, pp. 252-257, 28-31 May 2012.

[4] Prasanna, U.R.; Rathore, A.K., "Extended Range ZVS Active-Clamped Current-Fed Full-Bridge Isolated DC/DC Converter for Fuel Cell Applications: Analysis, Design, and Experimental Results," IEEE Transactions on Industrial Electronics, vol. 60, no. 7, pp. 2661-2672, July 2013.

[5] Iannello, C.; Shiguo Luo; Batarseh, I., "Small-signal and transient analysis of a full-bridge, zero-current-switched PWM converter using an average model," IEEE Transactions on Power Electronics, vol.18, no.3, pp.793-801, May 2003.

Analysis and Control of Isolated Current-fed Full Bridge Converter in Fuel Cell System

 ABSTRACT:

Fuel cells are considered as one of the most prominent sources of green energy in future. However, the potential efficiency of fuel cell will he untapped unless an efficient method can be used to Convert the fuel cell low voltage to high voltage grid or user load. Many topologies have been proposed for such applications. However, most of them consider the fuel cell as an voltage source instead of a current source. In this paper, an isolated current-fed full bridge boost converter is proposed as the front end of the fuel cell system, which is more compatible with the fuel cell particularities. Small signal analysis is applied to the compiler and current control method is used. Simulation and experiment results are shown to ,verify the analysis.

SOFTWARE: MATLAB/SIMULINK

CIRCUIT DIAGRAM:

Fig. 1. (a) Conventional full bridge current-fed convener; (b) Proposed full

bridge current·fed boost converter

EXPECTED SIMULATION RESULTS:

Fig. 2. Main wavefonns of the proposed converter (simulated)

Fig. 3. Main waveforms of the proposed converter when V_g = 5V. I_L = 6A

(experiment)

Fig. 4. Output voltage and inductor current with PI voltage control (simulated)

Fig. 5. Output voltage and inductor current with current control (simulated)

Fig. 6. Output voltage and inductor current with current control during load

changing (experiment)

CONCLUSION:

In order to speed up the market acceptance of EVs/HEVs, the capital cost in charging infrastructure needs to lower as much as possible. This paper has presented an improved asymmetric half-bridge converter-fed SRM drive to provide both driving and on-board DC and AC charging functions so that the reliance on off-board charging stations is reduced.  The main contributions of this paper are: (i) it combines the split converter topology with central tapped SRM windings to improve the system reliability. (ii) the developed control strategy enables the vehicle to be charged by both DC and AC power subject to availability of power sources. (iii) the battery energy balance strategy is developed to handle unequal SoC scenarios. Even through a voltage imbalance of up to 20% in the battery occurs, the impact on the driving performance is rather limited. (iv) the state-of-charge of the batteries is coordinated by the hysteresis control to optimize the battery performance; the THD of the grid-side current is 3.7% with a lower switching frequency.  It needs to point out that this is a proof-of-concept study based on a 150 W SRM and low-voltage power for simulation and experiments. In the further work, the test facility will be scaled up to 50 kW.

REFERENCES:

[1] B. K. Bose, “Global energy scenario and impact of power electronics in 21st Century,” IEEE Trans. Ind. Electron., vol. 60, no. 7, pp. 2638- 2651, Jul. 2013.

[2] J. de Santiago, H. Bernhoff, B. Ekergård, S. Eriksson, S. Ferhatovic, R. Waters, and M. Leijon, “Electrical motor drivelines in commercial all-electric vehicles: a review,” IEEE Trans. Veh. Technol., vol. 61, no. 2, pp. 475-484, Feb. 2012.

[3] A. Chiba, K. Kiyota, N. Hoshi, M. Takemoto, S. Ogasawara, “Development of a rare-earth-free SR motor with high torque density for hybrid vehicles,” IEEE Trans. Energy Convers., vol. 30, no. 1, pp.175-182, Mar. 2015.

[4] K. Kiyota, and A. Chiba, “Design of switched reluctance motor competitive to 60-Kw IPMSM in third-generation hybrid electric vehicle,” IEEE Trans. Ind. Appl., vol. 48, no. 6, pp. 2303-2309, Nov./Dec. 2012.

[5] S. E. Schulz, and K. M. Rahman, “High-performance digital PI current regulator for EV switched reluctance motor drives,” IEEE Trans. Ind. Appl., vol. 39, no. 4, pp. 1118-1126, Jul./Aug. 2003.
